A reliable center for your important footages

The X5S NVR is designed to manage large- scale videos generated from security needs. In addition to a storage capacity that can be expanded to 8TB2, the X5S also receives data and video files from up to 8 connected Wi-Fi cameras3 at the same time.

No detail is overlooked

Connecting the X5S to an additional monitor offers even more convenience for multi-camera viewing – the user can display the footages collected by all connected cameras simultaneously on one screen. It supports up to 3K resolution for live or history videos, so you’ll hardly miss a thing.

• Data from EZVIZ Lab’s test results in open environment. Will vary with the Wi Fi frequency, camera location, the transfer technology, and other environmental factors.
• The X5S only supports HDD storage. The HDD device should be purchased additionally. Please confirm the compatibility before purchasing.
• The X5S is available in two versions: the X5S-4W supports connecting up to 4 Wi-Fi cameras, and the X5S-8W supports up to 8 Wi-Fi cameras.

Specifications : CS-X5S-R100-4W, CS-X5S-R100-8W

IPC Access Capability

• Wireless/Wired IPC Access Capability :  3K * 4 / 3K * 8
• Wired IPC Access Capability : 3K * 4 (X5S-4W) / 3K * 8 (X5S-8W)

Network Parameter

• Antenna Number : 2
• Max Wireless Range : 100m
• Radio Frequency : 2.4G
• Ethernet Port : One 10/100M adaptable Ethernet interface
• Required Access Bandwidth : 50Mbps / 100Mbps

Video Output

• VGA : 1 channel (identical to HDMI output) resolution up to 1920*1080/60Hz
• HDMI : 1 channel 1 channel (identical to HDMI output) resolution up to 1920*1080/60Hz resolution up to 2592*1944/30HZ

Audio/Video Codec

• Recording Resolution : 3K/2K+/2K/1080p/UXGA/720p/V- GA/4CIF/2CIF/CIF/QCIF
• Video Compression : H.264, H.265
• Decode Playback : Supports 4*3K / Supports 8*3K

Video Recording Management

• Video Recording mode : Manual video recording ; Motion detection recording ;Scheduled video recording ; Event triggered recording
• Backup Mode : Hard disk backup, Internet application backup
• Playback Mode : Instant playback ; Normal playback ; Event playback ; Tag playback; Log event playback

Open Protocol

• Open Protocol Support : HIKVISION, ONVIF(2.5)

HDD

• Interface Type : One Built-in SATA
• Capability : Supports 1TB to 8TB 3.5-inch HDD

External Interface

• Audio Input/ Output : Not support
• Hardware Reset : Supports
• USB2.0 Interface : 1

Specifications : CS-X5S-R100-4W, CS-X5S-R100-8W

Dimensions

• Product Dimensions : 235 × 270 × 44.5 mm (9.25 × 10.6 × 1.75 inch)
• Packaging Dimensions : 387 × 362 × 75 mm (15.2 × 14.3 × 3 inch)

Power Supply

• DC : 12V/1.5A

Consumption

• Standby status : ≤8W

Weight

• Net Weight : 932 g

In the box

• X5S NVR × 1
• Power Adapter × 1
• Mouse × 1
• Screw Kit × 1
• Regulatory Information × 2
• Quick Start Guide × 1

Certifications

• CE / UL / RoHS / WEEE / REACH

Extra Information

• SKU: EZVIZX5S8W
• Warranty: 2 Years
• Brand: Ezviz
• Technology: IP
• Product Type: NVR
• PDF: View PDF
