Tyco Illustra ISE-B04V014S-N H.265 4MP Manual Verifocal IR Bullet Network Camera

Name: Tyco Illustra ISE-B04V014S-N H.265 4MP Manual Verifocal IR Bullet Network Camera
Brand: Tyco
SKU: ISEB04V014SN
Price: 43900.0 INR
Availability: InStock
Rating: 5.0 (10 reviews)

Product SKU: ISEB04V014SN

Available:

Only 12 items in stock

12 items in stock

In stock

Pre-order

Out of stock

Tyco Illustra Camera ISE-B04V014S-N H.265 4MP Manual V/F IR Bullet N/W Camera, 2.8-12mm, 50M IR, Micro SD, DC12V/PoE, IP67/IK10, IVA

Key Benefits

4MP resolution (2560×1440), H.265
30fps @ 4MP
True day / night
Up to 50m IR distance
3D DNR, HLC & BLC, WDR
Triple streams
Smart codec by ROI
PoE power supply
Basic intelligent video analytics
IP67 / IK10
NDAA Compliant

Rs. 43,900.00

~~Rs. 55,000.00~~

Want it delivered by

Data Sheet

Video

PDF

view pdf

Return & Refund Shipping Info

Description
Reviews

The illustra Standard Manual Varifocal Bullet camera from Tyco offers resolution upto 4MP with inbuilt IR for operations in low light conditions. The affordable feature-rich camera supports intelligent video analytics (IVA) at the edge to cater to multiple site requirements. It captures high resolution images in variety of lighting conditions with features such as Auto Day/Night, Defog and Wide Dynamic Range. Rated IP67 & IK10 for an additional degree of environmental and vandal protection respectively.

Exceptional Image Quality

With 4MP @ 30fps the camera produces exceptionally high Image quality. It supports H.265/H.264 video compression, multi-level video streaming configuration, support Basic/ Main/ High Profile H.265 encoding complexity. This bullet camera can support up to 128 GB Micro SD/SDHC/SDXC card storage and 10M/100M Ethernet Port.

Authentication Support for Higher Security

Illustra IP cameras have been designed to protect against cyber-threats. Additionally, for greater security, the Camera supports three-level user authentication– management, user and password authorization, IP address filtering and anonymous access. Basic authentication is supportable in Web browser configuration.

ONVIF Support

Camera supports ONVIF (Profile S & G) protocol, up to 3 streams providing flexibility of video stream recording, live view at different resolutions and bitrate configuration options.

Specifications

Camera
Image Sensor	1 / 2.7, Progressive Scan CMOS
Effective Pixels	2560 × 1440
Min. Illumination	Color: 0.011 Lux @ F1.2, AGC ON; 0 lux with IR Color: 0.016 Lux, @ F1.4, AGC ON; 0 lux with IR
Shutter Speed	1 s to 1/100,000 s
S/N Ratio	≥52 dB
Angle Adjustment	Any angle
Lens
Focal Length	2.8 - 12 mm @ F1.4, manual varifocal zoom lens
Iris Type	Fixed Iris
Field of View (H/V)	Horizontal: 94° ~ 35.7°, Vertical: 62.2° ~ 20.5°
Lens Mount	ø 14
Video
Video Compression	H.265 / H.264
H.264 Compression Standard	Base Line / Main Profile / High Profile
H.265 Compression Standard	Main Profile @ Leve4.1 High Tier
Resolution	4MP(2560×1440), 3MP(2304×1296), 1080P(1920x1080), 720P(1280x720), D1, CIF, 480 x 240
Max. Frame Rate	30fps @ 4MP (2560×1440)
Video Bit Rate	64Kbps - 5 Mbps
Multiple Streaming	Triple streams
Main Stream	60Hz: 4MP/3MP/1080P/720P(1-30fps); 50Hz: 4MP/3MP/1080P/720P(1-25fps)
Sub Stream	60Hz: 720P(1-15fps)/D1/CIF (1-30fps); 50Hz: 720P(1-12fps)/D1(1-25fps)/CIF(1-25fps)
Third Stream	60Hz: D1/CIF/480x240(1-30fps); 50Hz: D1/CIF/480x240(1-25fps)
Smart Codec	ROI, 3 zones
Quality Control	Five levels under VBR; Freely adjustable under CBR
Image Setting	time stamp, text overlay, flip & mirror, ROI, Saturation, Brightness, Chroma, Contrast, Wide Dynamic, Sharpen, white balance, video rotation, Scheduled profile settings, AGC
Operational
Day & Night	IR cut filter with auto switch
Wide Dynamic Range	Yes
IR Distance	Up to 50M
Digital Zoom	Yes
Image Features	Defog, BLC, HLC, 2D/3D DNR
Corridor Pattern	Yes
Video Privacy	4 zones video mask
Intelligent Video Analytics	Object removal (object left/missing detection), scene change and video blur detection, intrusion and line crossing

Alarm Triggers	Motion detection, Intelligent video analytics, Network disconnect, video tampering, IP address conflict, illegal login, SD Card full, SD Card error, Alarm input, Alarm output
Edge Storage	Built-in micro SD card slot, up to 128GB
Network
Network Protocol	TCP/IP, UDP, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP, UPnP, Unicast, Multicast, ICMP, HTTP, HTTPS, DNS, DDNS, RTP, RTCP, IGMP, 802.1X, QoS, IPv4, IPv6
Cyber Security	HTTPS / IP Filter / IEEE 802.1X / Blacklist & whitelist / account security / telnet access control / serial password
Online Connection	Support simultaneous monitoring for up to 4 users; Support multi-stream real time transmission
Remote Monitoring	Webviewer browsing, Holis Pro, Holis Lite, ExacqVision, Victor
API	ONVIF Profile (S & G), HAPI3
Interface
Network	1 RJ45 10M/100M self-adaptive thernet port
Onboard Storage	Built-in micro SD/SDHC/SDXC slot
Hardware Reset	Yes
Environmental
Operating Temperature	- 30 °C to 60 °C
Operating Humidity	10 % to 90 % relative humidity
Ingress Protection	IP67
Vandal Resistance	IK10
General
Power Supply	DC12V / PoE
Power Consumption	< 10W
Dimensions ( mm )	225.7x86.7x83.8
Material	Metals
Weight	≈ 0.7kg
Installation	Wall mounting, ceiling mounting
Warranty	3 years
Regulatory
Emissions	FCC Part 15.107 Class A, FCC Part 15.109 Class A , EN 55032, EN 55035 (IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8)
Immunity	EN 55030-4
Safety	UL 62368-1, IEC 62368-1 EN 62368-1, CAN/CSA C22.2 No. 62368-1-14, J62368-1, AS/NZA 62368.1
Environment	RoHS (IEC 62321-3-1, IEC 62321-5, IEC 62321-4, IEC 62321-6, IEC 62321-7, IEC 62321-7-2, IEC 62321-8), WEEE, REACH
NDAA Compliant	Yes

Ordering Information

	Model Number	Description
Camera	ISE-B04V014S-N	H.265 4MP Manual V/F IR Bullet N/W Camera, 2.8-12mm, 50M IR, Micro SD, DC12V/PoE, IP67/IK10, IVA
Accessories	ISMNBCB01	Conduit Box for mini IR Bullet
Accessories	ISMNBBB01	Backbox for mini IR Bullet
Accessories	ISMNBPD01	Pendant mount for mini IR Bullet (use with ISMNBCB01)
Accessories	ISMNBPM01	Pole mount for mini IR Bullet (use with ISMNBCB01)
Accessories	ISMNBCM01	Corner mount for mini IR Bullet (use with ISMNBCB01)
