Hikvision DS-2CD1723G0-I 2MP IP Bullet Camera

Available Model

• DS-2CD1723G0-I (2.8 mm to 12 mm)
• DS-2CD1723G0-IZ (2.8 mm to 12 mm)

Camera Specification

• Image Sensor : 1/2.8" progressive scan CMOS
• Min. Illumination : Color: 0.01 Lux @(F1.2, AGC ON), 0.018Lux @ (F1.6, AGC ON)
• Shutter Speed : 1/3 s to 1/100, 000 s, support slow shutter
• Slow Shutter : Yes
• Auto-Iris : No
• Day &Night : IR cut filter
• Digital Noise Reduction : 3D DNR
• WDR : Digital WDR
• Angle Adjustment : Pan: 0° to 355°, tilt: 0°to 70°, rotation: 0° to 360°

Lens

• Focal length : 2.8 to 12 mm
• Aperture : F1.6
• Focus : -I: Manual-IZ: Auto
• FOV : Horizontal field of view: 98°to 34°, Vertical field of view: 52°to 19°, Diagonal field of view: 116°to 40°
• Lens Mount : Φ14

IR

• IR Range : Up to 30 m
• Wavelength : 850 nm

Compression Standard

• Video Compression : Main stream: H.265/H.264, Sub stream: H.265/H.264/MJPEG
• H.264 Type : Baseline Profile/Main Profile/High Profile
• H.264+ : Main stream supports
• H.265 Type : Main Profile
• H.265+ : Main stream supports
• Video Bit Rate : 32 Kbps to 8 Mbps
• Smart Feature-set
• Region of Interest : 1 fixed region for main stream and sub-stream


• Max. Resolution : 1920 × 1080
• Main Stream : Max. Frame Rate, 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720), 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
• Sub-stream : Max. Frame Rate, 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240), 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
• Image Enhancement : BLC, 3D DNR
• Image Setting : Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
• Day/Night Switch : Auto, scheduled

Network

• Network Storage : Support Micro SD/SDHC/SDXC card (128G ), local storage and NAS (NFS,SMB/CIFS), ANR
• Alarm Trigger : Motion detection, video tampering alarm, network disconnected, IP address conflicted, illegal login
• Protocols : TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
• General Function : One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark
• Firmware Version : 5.5.2
• API : ONVIF (PROFILE S, PROFILE G), ISAPI
• Simultaneous Live View : Up to 6 channels
• User/Host : Up to 32 users, 3 levels: Administrator, Operator and User
• Client : iVMS-4200, iVMS-4500, iVMS-5200
• Web Browser : IIE7+, Chrome18-42, Firefox5.0+, Safari5.02+

Interface

• Communication : Interface 1 RJ45 10M/100M self-adaptive Ethernet port
• Video Output (Without -Z) : 1Vp-p composite output (75 Ω/BNC)

General

• Operating Conditions : -30 °C to 50 °C (-22 °F to 122 °F), humidity: 95% or less (non-condensing)
• Power Supply : 12 VDC ± 25%, 5.5 mm coaxial power plug, PoE (802.3af, class 3)
• Power Consumption and Current : -IZ: 12 VDC, 0.8 A, Max: 10 W; PoE: (802.3af, 37 V to 57 V), 0.35 A to 0.2 A, Max: 12 W-I: 12 VDC, 0.5 A, Max: 6 W; PoE: (802.3af, 37 V to 57 V), 0.22 A to 0.14 A, Max: 8 W
• Protection Level : IP67, IK10
• TVS : 2000V lightning protection, surge protection and voltage transient protection
• Material : Metal & Plastic
• Dimensions : Camera: Φ 141 mm × 99.9 mm (5.6" × 3.9"), With package: 140 mm × 140 mm × 154 mm (5.5" × 5.5" × 6.1")
• Weight :  Camera: Approx. 830 g (1.8 lb.), With package: Approx. 1070 g (2.4 lb.)

Extra Information

• SKU: DS2CD1723G0I
• Warranty: 2 Years
• Brand: Hikvision
• Megapixel: 2
• Technology: IP
• Camera Type: Bullet
• Product Type: Camera
• PDF: View PDF
