Hikvision DS-2CD1743G0-I 4MP IP Bullet Camera
Short description :
- 1/3" progressive scan CMOS
- 3D DNR (Digital Noise Reduction)
- 2560 × 1440@20fps
- Up to 30 m IR range
- 2.8 mm to 12 mm manual/motorized (with-Z) vari-focal lens
- PoE (Power over Ethernet)
- IP67
- H.265+, H.265, H.264+, H.264
- Dual stream
- 120 dB WDR (Wide Dynamic Range)
Refund policy
Refund policy
we suggest to reach us out on +919825257770 or info@techfinder.in regarding the product you wish to shop before making an online purchase. Once you have made the transaction through techfinder, unless a legitimate reason, the order can neither be returned nor cancelled.In case of legitimate reason the return is acceptable only within 2 days(with video proof). Read more...
Shipping Info
Shipping Info
We always believe to provide smooth and easy shipping methods to our valued customers. We are committed to providing timely service and ensuring your satisfaction. Orders will be dispatched within 2 to 7 days, depending on the specific order and the product's availability. We appreciate your patience and understanding as we work to fulfill your request. The orders for the user are shipped through registered domestic courier companies and/or speed post only. Read more...
Camera Specification
- Image Sensor : 1/3" progressive scan CMOS
- Min. Illumination : Color: 0.01 Lux @(F1.2, AGC ON), 0.018Lux @ (F1.6, AGC ON)
- Shutter Speed : 1/3 s to 1/100, 000 s, support slow shutter
- Slow Shutter : Yes
- Auto-Iris : No
- Day &Night : IR cut filter
- Digital Noise Reduction : 3D DNR
- WDR : 120 dB
- Angle Adjustment : Pan: 0° to 355°, tilt: 0°to 70°, rotation: 0° to 360°
Lens
- Focal Length : 2.8 to 12 mm
- Aperture : F1.6
- Focus : -I: Manual-IZ: Auto
- FOV : Horizontal field of view: 98°to 28°, Vertical field of view: 51°to 16°, Diagonal field of view: 115°to 32°
- Lens Mount : Φ14
IR
- IR Range : Up to 30 m
- Wavelength : 850 nm
Compression Standard
- Video Compression : Main stream: H.265/H.264, Sub stream: H.265/H.264/MJPEG
- H.264 Type : Baseline Profile/Main Profile/High Profile
- H.264+ : Main stream supports
- H.265 Type : Main Profile
- H.265+ : Main stream supports
- Video Bit Rate : 32 Kbps to 8 Mbps
- Smart Feature-set
- Region of Interest : 1 fixed region for main stream and sub-stream
- Max. Resolution : 2560 × 1440
- Main Stream : Max. Frame Rate, 50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720), 60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
- Sub-stream : Max. Frame Rate, 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240), 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
- Image Enhancement : BLC, 3D DNR
- Image Setting : Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
- Day/Night Switch : Auto, scheduled
Network
- Network Storage : Support Micro SD/SDHC/SDXC card (128G ), local storage and NAS (NFS,SMB/CIFS), ANR
- Alarm Trigger : Motion detection, video tampering alarm, network disconnected, IP address conflicted, illegal login
- Protocols : TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
- General Function : One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
- Firmware Version : 5.5.3
- API : ONVIF (PROFILE S, PROFILE G), ISAPI
- Simultaneous Live View : Up to 6 channels
- User/Host : Up to 32 users, 3 levels: Administrator, Operator and User
- Client : iVMS-4200, Hik-Connect, iVMS-5200
- Web Browser : IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
Interface
- Communication Interface : 1 RJ45 10M/100M self-adaptive Ethernet port
- Video Output (Without -Z) : 1Vp-p composite output (75 Ω/BNC)
- Reset Button : Yes
- Operating Conditions : -30 °C to 50 °C (-22 °F to 122 °F), humidity: 95% or less (non-condensing)
General :
- Power Supply : 12 VDC ± 25%, 5.5 mm coaxial power plug, PoE (802.3af, class 3)
- Power Consumption and Current : -IZ: 12 VDC, 0.8 A, Max: 10 W; PoE: (802.3af, 36 V to 57 V), 0.35 A to 0.2 A, Max: 12 W, -I: 12 VDC, 0.5 A, Max: 6 W; PoE: (802.3af, 36 V to 57 V), 0.22 A to 0.14 A, Max: 8 W
- Protection Level : IP67, IK10
- TVS : 2000V lightning protection, surge protection and voltage transient protection
- Material :Metal & Plastic
- Dimensions : Camera: Φ 141 mm × 99.9 mm (5.6" × 3.9"), With package: 140 mm × 140 mm × 154 mm (5.5" × 5.5" × 6.1")
- Weight : Camera: approx. 820 g (1.8 lb.), With package: approx. 1200 g (2.6 lb.)
Extra Information
- SKU: DS2CD1743G0I
- Warranty: 2 Years
- Brand: Hikvision
- Megapixel: 2
- Technology: IP
- Camera Type: Bullet
- Product Type: Camera
- PDF: View PDF
