16 Zone Addressable Fire Alarm Control Panel

Description

The AW-CFP2166 series conventional fire alarm panel is designed based on EN54 part 2＆4 standard. And it is the central part of conventional fire alarm system, designed for applications requiring smoke detector, bell, manual pull stations, and sprinkler supervision. Each zone can be disabled by a button. The basic unit offers 1 to 8 zones of initiation, up to 16 zones for larger applications.

• Item : Conventional fire alarm panel
• Model No. : AW-CFP2166
• Mains supply voltage : 110VACor 240VAC
• Internal power supply : 24VDC
• Total output current limited : 3A@240VAC
• Batteries (Default Configuration) : 12V2AH*2=24
• End of Line deviece : 6.8kΩ,5% tolerance,0.25W(color code-bule,grey,red,gold)
• End of line resistor value : 6.8kΩ,5% tolerance,0.25W(color code-bule,grey,red,gold)

Extra Information

• SKU: Fire16
• Warranty: 2 Years
• Brand: VisionXP
• Technology: Others
• Product Type: Fire Alarm Systems
• PDF: View PDF
