UNV Uniview IPC3614LB-AF28K-DL 4MP HD ColorHunter Fixed Eyeball POE Network Dome Camera With Audio
Key Features
- High quality image with 4 MP, 1/3.0" CMOS sensor
- 4 MP (2560 × 1440)@25/20 fps; 3 MP (2304 × 1296)@30/25 fps; 1080P (1920 × 1080)@30/25 fps
- Ultra 265, H.265, H.264, MJPEG
- Supports 9:16 corridor mode
- Built-in mic
- Smart IR, up to 30 m (98.4 ft.) IR distance
- Warm light, up to 30 m (98.4 ft.) warm light distance
- 2D/3D DNR (digital noise reduction)
- MicroSD, up to 512 GB
- IP67 protection
- Supports PoE power supply
- 3-axis
Refund policy
Refund policy
we suggest to reach us out on +919825257770 or info@techfinder.in regarding the product you wish to shop before making an online purchase. Once you have made the transaction through techfinder, unless a legitimate reason, the order can neither be returned nor cancelled.In case of legitimate reason the return is acceptable only within 2 days(with video proof). Read more...
Shipping Info
Shipping Info
We always believe to provide smooth and easy shipping methods to our valued customers. We are committed to providing timely service and ensuring your satisfaction. Orders will be dispatched within 2 to 7 days, depending on the specific order and the product's availability. We appreciate your patience and understanding as we work to fulfill your request. The orders for the user are shipped through registered domestic courier companies and/or speed post only. Read more...
|
Model |
IPC3614LB-AF28K-DL |
|
Camera |
|
|
Max Resolution |
4 MP |
|
Sensor |
1/3.0" CMOS |
|
Min. Illumination |
Color: 0.01 Lux ( F1.6, AGC ON), 0 Lux with IR |
|
Day/Night |
IR-cut filter with auto switch (ICR) |
|
Shutter |
Auto/Manual, 1 ~ 1/100000s |
|
Adjustment Angle |
Pan: 0° to 360°, Tilt: 0° to 80°, Rotate: 0° to 360° |
|
S/N |
>52 dB |
|
WDR |
DWDR |
|
Lens |
|
|
Focal Length |
2.8 mm |
|
Iris Type |
Fixed |
|
Iris |
F1.6 |
|
Field of View (H) |
95.1° |
|
Field of View (V) |
51.6° |
|
Field of View (D) |
111.6° |
|
DORI |
|
|
DORI Distance (Lens) |
2.8 mm |
|
DORI Distance (Detect) |
63.0 m (206.7 ft.) |
|
DORI Distance (Observe) |
25.2 m (82.7 ft.) |
|
DORI Distance (Recognize) |
12.6 m (41.3 ft.) |
|
DORI Distance (Identify) |
6.3 m (20.7 ft.) |
|
Illuminator |
|
|
Supplemental Light |
Dual light |
|
Illumination Distance (IR) |
30 m (98.4 ft.) |
|
Illumination Distance (Warm Light) |
30 m (98.4 ft.) |
|
Wavelength |
850 nm |
|
IR On/Off Control |
Auto/Manual |
|
Video |
|
|
Video Compression |
Ultra 265, H.265, H.264, MJPEG |
|
H.264 Code Profile |
Baseline profile, Main profile, High profile |
|
Frame Rate |
Main Stream: 4 MP (2560 × 1440), max. 25 fps; 3 MP (2304 × 1296), max. 30 fps; 1080P (1920 × 1080), max. 30 fps; 720P (1280 × 720), max. 30 fps Sub Stream: D1 (720 × 576), max. 30 fps; 640 × 360, max. 30 fps; 2CIF (704 × 288), max. 30 fps; CIF (352 × 288), max. 30 fps; |
|
Video Bit Rate |
128 Kbps to 6144 Kbps |
|
U-code |
Support |
|
OSD |
Up to 4 OSDs |
|
Privacy Mask |
Up to 4 areas |
|
ROI |
Support |
|
Video Stream |
Dual streams |
|
Image |
|
|
White Balance |
Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2 |
|
Digital Noise Reduction |
2D/3D DNR |
|
Smart IR |
Support |
|
Flip |
Normal, Flip vertical, Flip horizontal, 180°, 90° Clockwise, 90° Anti-clockwise |
|
Dewarping |
N/A |
|
HLC |
Support |
|
BLC |
Support |
|
Defog |
Digital defog |
|
Events |
|
|
Basic Detection |
Motion detection, Ultra motion detection, Tampering alarm, Audio detection |
|
General Function |
Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, HTTP authentication |
|
Audio |
|
|
Audio Compression |
G.711U, G.711A |
|
Audio Bitrate |
64 Kbps |
|
Two-way Audio |
N/A |
|
Suppression |
Support |
|
Sampling Rate |
8 kHz |
|
Storage |
|
|
Edge Storage |
MicroSD, up to 512 GB |
|
Network Storage |
ANR, NAS (NFS) |
|
Network |
|
|
Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, QoS, SSL/TLS, SNMP |
|
Compatible Integration |
ONVIF (Profile S, Profile G, Profile T), API, SDK |
|
User/Host |
Up to 32 users, 2 user levels: administrator and common user |
|
Security |
Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF |
|
Client |
EZStation, APP |
|
Web Browser |
Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+, Plug-in free live view: Chrome 57+, Firefox 58+, Edge 16+ |
|
Interface |
|
|
Audio I/O |
N/A |
|
Alarm I/O |
N/A |
|
Serial Port |
N/A |
|
Built-in Mic |
Support |
|
Built-in Speaker |
N/A |
|
WIFI |
N/A |
|
Network |
1 × RJ45 10 M/100 M Base-TX Ethernet |
|
Video Output |
N/A |
|
Certification |
|
|
EMC |
CE-EMC (EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 50130) FCC (FCC 47 CFR part15 B) |
|
Safety |
CE LVD (EN 62368-1) UL/CUL (UL 62368-1, CAN/CSA C22.2 No. 62368-1) |
|
Environment |
CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); |
|
Protection |
IP67 (IEC 60529) |
|
General |
|
|
Power |
DC 12 V±25%, PoE (IEEE 802.3af) |
|
Power Consumption |
Max. 2.8 W |
|
Power Interface |
Ø5.5 mm coaxial power plug |
|
Dimensions |
Ø118 mm × 98 mm (Ø4.6" × 3.9") (Ø × H) |
|
Weight |
0.29 kg (0.64 lb.) |
|
Material |
Metal + Plastic |
|
Storage Environment |
-30 ℃ to 60 ℃ (-22 ℉ to 140 ℉), Humidity: ≤ 95% RH (non-condensing) |
|
Working Environment |
-30 ℃ to 60 ℃ (-22 ℉ to 140 ℉), Humidity: ≤ 95% RH (non-condensing) |
|
Surge Protection |
4 KV |
|
Reset Button |
N/A |
|
Web Client Language |
4 Languages: English, Russian, Spanish, Vietnamese |
