Honeywell Impact I-HPNVR-1664 NVR 64ch 16 Sata 4 HDMI 640mbps Network Video Recorder
FEATURES AND BENEFITS
- Up to 64 Channel Input
- 16 Sata Interfaces, Up To 18TB (Enterprise Class Only)
- H.265+/H.265/H.264 Video Formats
- 4 HDMI Port,1 VGA, USB3.0*2, USB2.0*1 Support
- 2×RJ45 Self-adaptive 10/100/1000 Mbps Network Interfaces
- Supports live view,
- storage and playback of the connected camera at up to 12MP resolution
- Connectable
- to the Third Party Network Cameras
Refund policy
Refund policy
we suggest to reach us out on +919825257770 or info@techfinder.in regarding the product you wish to shop before making an online purchase. Once you have made the transaction through techfinder, unless a legitimate reason, the order can neither be returned nor cancelled.In case of legitimate reason the return is acceptable only within 2 days(with video proof). Read more...
Shipping Info
Shipping Info
We always believe to provide smooth and easy shipping methods to our valued customers. We are committed to providing timely service and ensuring your satisfaction. Orders will be dispatched within 2 to 7 days, depending on the specific order and the product's availability. We appreciate your patience and understanding as we work to fulfill your request. The orders for the user are shipped through registered domestic courier companies and/or speed post only. Read more...
Specification
|
VIDEO |
|
|
Resolution |
12MP, 8MP, 5MP, 3MP, 2MP(1080P), 1.3MP(960P), 1.0MP(720P) |
|
Incoming Bandwidth |
640M |
|
Outgoing Bandwidth |
640M |
|
PERFORMANCE |
|
|
|
Live Playback |
Compression |
Audio: G.711A/G.711U Video : H.264/H.265/H.264+/H.265+ |
|
|
Frame rate |
4K:240fps 4MP:480fps 2MP:960fps |
|
|
Event |
MD(Sensitivity Level 1~8) Videlo loss Beep, Email, Push notification to Mobile APP |
|
|
Playback function |
Fast forward / backward (2x, 4x, 8x,16x) Slow forward (1/2x, 1/4x, 1/8x,1/16x) |
|
|
Playback |
Max 16CH playback |
|
RAID |
RAID Type |
RAID0, RAID1, RAID5, RAID6, RAID10 |
|
|
Fisheye |
Support |
|
UI/Monitoring |
WEB |
IE10/11, Safari V12.1 above, Firefox V.52 above, Google chrome V.57 above, Edge V.79 above |
|
Support AI |
|
Face Detection Pedestrian Detection Vehicle Detection Cross Counting Heat Map Crowd Density Detection Perimeter Intrusion Detection Line Crossing Detection Queue Legth Detection License Plate Detection Rare Sound Detection |
|
INTERFACE |
|
|
|
P/W Reset |
|
Yes |
|
Moniters |
HDMI |
3(1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080, 1920*1080, 1600*1200, 1920*1200, 3840*2160/7680*4320/EDID) Async out *If the output resolution of HDMI 1 is set to 8K, the maximum output resolution of HDMI 3 and 4 will be limited to 1080P, and HDMI 2 will be disabled. 1(1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 /EDID) Async out |
|
|
Ethernet |
2 RJ45 100/1000 Base-T |
|
|
USB |
USB2.0*1(front) , USB3.0*2(rear) |
|
|
Audio Out |
1 |
|
|
E-sata |
1 |
|
|
HDD |
16 SATA HDD, up to 18TB (Enterprise-Class) |
|
|
Line in |
1 |
|
|
RS232 |
1*RJ45 |
|
|
Rs485 |
1 |
|
|
Alarm Input/out |
16 in /4 out |
|
GENERAL |
|
|
|
OSD Language |
|
English |
|
Mechanical Design |
Dimension (WxDxH) |
440*460*149mm |
|
Electrical |
Input Voltage/Current |
ATX 250W |
|
|
Power consumption (excluding hard disk) |
8W |
|
Environmental |
Operating Temperature/ Humidity |
Temperature : -10°C~+50°C (14°F ~ 122°F) Humidity : Less than 90%RH |
The I-HPNVR-1664 is a robust 64-channel NVR compatible with third-party network cameras, enabling live viewing, storage, and playback at resolutions up to 12MP. Equipped with intelligent analytics such as facial recognition and license plate recognition, it enhances security with alarm inputs and outputs. It offers flexible connectivity and monitoring through various interface options and remote access support.
