Yadon Y100-4P2UP/B 4port POE & 2 UP Link 10/100mbps Network Switch with Inbuilt UPS Lowest Price Buy Online Store

Product Features

• Powered by Lithium-ion Battery
• Extend up to 250mtr Cat6
• Support All IP Cameras & NVR
• Support All WiFi Routers
• Auto Detect MDI/MDIX
• 6KV Lightning Protection
• 8POE Port and 2 Uplink
• Fanless Design

Output Connection

• DC Female Jack - 1 (12.6v + - 5% for NVR)
• DC Female Jack - 2 (12v + - 5% for WiFi)
• DC Female Jack - 3 (5V + - 5% Optional)

Inside Box

• POE Switch - 1
• DC Adaptor 14.5v-5Amp Charger-1
• DC Male Jack-2
• Caution Card - 1
• Warranty Card - 1

Specifications

General

• Type : Unmanaged
• Model : 8Port PoE Ups Switch Y100-8P2UP/B 10/100Mbps Switch with PowerBackup|
• Series : PoE
• VLAN Support : No
• In The Box : 1unit of 8 PORT POE SWITCH with UPS
• Color : Black
• Brand : YADON

Operating Conditions

• Operational Temperature : -10 to +50
• Storage Temperature : -10 to +50

Power

• Power Over Ethernet : 65 W
• Power Adapter Input : 120 to 250v AC
• Power Requirement : 14volt 5amp DC

Network Ports

• Number of Ethernet ports : 8
• Speed : 100 Mbps

Supported Protocols

• Supported Protocols : IEEE802.3AF/AT

Network Features

• Bandwidth : 0.1 Gbps
• Latency : zero

Indicators

• LEDs : 3 LED INDICATOR

Additional Features

• Additional Features : 250m: Turn on the extension(E) switch, Lithium-ion Powerd 13200MAH, Battery Protection over voltage, No delay battery boot up, 6 KV surge protected, overload protection, Energy efficiency

Dimensions

• Mount Type : Wall Mount Option Available
• Height : 5 mm
• Width : 24 mm
• Depth : 15 mm
• Weight : 1200 g

Warranty

• Service Type : REPAIRED or REPLACE UNIT
• Covered in Warranty : MANUFACTURER DEFFECTS
• Not Covered in Warranty : PHYSICAL AND WATER DAMAGED
• Warranty Summary : Yadon india products is warranted against defects in materials and workmanship for a period of ONE (1) YEAR from the date of original retail purchase (“Warranty Period”) when used in accordance with refer to YADON INDIA user manuals.

Extra Information

• SKU: Y1008P2UPB
• Warranty: 2 Years
• Brand: YAD ON
• Product Type: POE
