Tyco Illustra ISV-X04N005SAF Standard 4MP Starlight Box Network Camera

Name: Tyco Illustra ISV-X04N005SAF Standard 4MP Starlight Box Network Camera
Brand: Tyco
SKU: ISVX04N005SAF
Price: 44500.0 INR
Availability: InStock
Rating: 5.0 (10 reviews)

Product SKU: ISVX04N005SAF

Available:

Only 3 items in stock

3 items in stock

In stock

Pre-order

Out of stock

Tyco ISV-X04N005SAF H.265 4MP Box N/W Camera, 1/1.8" CMOS, C/S, DC12V/ AC24V/ PoE, SD, Smart IVA, Facial Recognition / Identification

Key Features

4MP resolution (2560 × 1440), H.265
30fps@4MP, 60fps@2MP
True day / night
True WDR, up to 120dB
3D DNR, HLC & BLC
Defog
Triple streams
Smart codec by ROI
2-way audio & alarm in/out
Onboard storage
PoE power supply
Advanced intelligent video analytics
Facial Recognition/Identification
Smart non-false alarm

Rs. 44,500.00

~~Rs. 65,000.00~~

Want it delivered by

Data Sheet

Video

PDF

view pdf

Return & Refund Shipping Info

Description
Reviews

The Illustra 4MP Smart Starlight Box network Camera by Tyco provides improved low light video performance. It provides clear and relevant images regardless of lighting conditions, time-of-day or object movement. Combined with built-in video intelligence, starlight cameras can deliver detailed monochrome images where other cameras show no image at all. Additionally, this camera comes with a rich feature-set that includes True WDR, PoE, and 3D DNR to meet a wide variety of video surveillance applications.

Exceptional Image Quality

With 4MP @ 30fps and 2MP @ 60fps the camera produces exceptionally high Image quality. It supports H.265/H.264/MJPEG video compression, multi-level video streaming configura- tion, support Basic/Main/ High Profile H.265 encoding complexity. This box camera can support up to 128 GB Micro SD/SDHC/SDXC card storage, 10M/100M Ethernet Port, Audio I/O, dual channel stereo audio, Alarm I/O and CVBS analog output.

Authentication Support for Higher Security

Illustra IP cameras have been designed to protect against cyber-threats. Additionally, for greater security, the Camera supports three-level user authentication– management, user and password authorization, IP address filtering and anonymous access. Other vital security features include security certificates such as HTTPS, SSH, Support Creating Certificate and lock user IP feature for multiple login error. Basic authentication is supportable in Web browser configuration.

ONVIF Support

Camera supports ONVIF (Profile S, G & T) protocol, up to 3 streams providing flexibility of video stream recording, live view at different resolutions and bitrate configuration options.

Product Specifications

Camera
Image Sensor	1/1.8” Progressive Scan CMOS
Effective Pixels	1920 × 1080
Min. Illumination	0.005 Lux @ F1.2, AGC ON; 0.008 Lux @ F1.6, AGC ON
Shutter Speed	1 s to 1/100,000 s
S/N Ratio	≥52 dB
Lens
Focal Length	None
ABF	Yes
Iris Type	DC-Iris
Lens Mount	C/CS
Video
Video Compression	H.265 / H.264 / MJPEG
H.264 Compression Standard	Base Line / Main Profile / High Profile
H.265 Compression Standard	Main Profile @ Leve4.1 High Tier
Resolution	1080P(1920x1080), 720P(1280x720), D1, CIF, 480x240
Max. Frame Rate	30fps @ all resolution, 60fps @ 1080P
Video Bit Rate	128 Kbps - 10 Mbps
Multiple Streaming	Triple Streams
Main Stream	60Hz: 4MP(1-30fps) / 3MP(1-30fps) / 1080P(1-60fps) / 720P(1-30fps) 50Hz: 4MP(1-25fps) / 3MP(1-25fps) / 1080P(1-50fps) / 720P(1-25fps)
Sub Stream	60Hz: 1080P / 720P / D1 / CIF / 480×240 (1-30fps) 50Hz: 1080P / 720P / D1 / CIF / 480×240 (1-25fps)
Third Stream	60Hz : D1( 1-30fps ) / 480x240( 1-30fps ) / CIF( 1-30fps ) 50Hz : D1( 1-25fps ) / 480x240( 1-25fps ) / CIF( 1-25fps )
Smart Codec	ROI, 3 zones
Quality Control	Five levels under VBR; Freely adjustable under CBR
Image Setting	time stamp, text overlay, flip & mirror, ROI, Saturation, Brightness, Chroma, Contrast, Wide Dynamic, Sharpen, white balance, video rotation, Scheduled profile settings, AGC
Audio
Audio Communication	Bi-directional audio (2-way)
Audio Compression Format	G711ulaw / G711alaw
Audio Bit Rate	128 Kbps
Operational
Day & Night	IR cut filter with auto switch
Wide Dynamic Range	True WDR, 120dB
IR Distance	NA
Digital Zoom	Yes
Image Features	Defog, BLC, HLC, 2D/3D DNR
Corridor Pattern	Yes
Video Privacy	4 zones video mask

Intelligent Video Analytics	Perimeter Protection Target Exception Face Facial Counting Detection Detection Recognition Line crossing, region Line crossing Scene change, Face detection Facial Entering/Exiting/Intrusion human/motor video blur and and face Recognition / (human/motor vehicle/ vehicle/non-motor video color capture Identification non-motor vehicle vehicle counting cast detection classification)
Alarm Triggers	Motion detection, Intelligent video analytics, Network disconnect, video tampering, IP address conflict, illegal login, HDD full, HDD error, Alarm input, Alarm output
Edge Storage	Built-in micro SD card slot, up to 128GB
Backfilling	Supported
Network
Network Protocol	TCP/IP, UDP, DHCP, NTP, RTSP, PPPoE, SMTP, FTP, SNMP, UPnP, Unicast, Multicast, ICMP, HTTP, HTTPS, DNS, DDNS, RTP, RTCP, IGMP, 802.1X, QoS, IPv4, IPv6, Bonjour, ARP
Cyber Security	HTTPS / IP Filter / IEEE 802.1X / Blacklist & whitelist / account security / telnet access control / serial password
Online Connection	Support simultaneous monitoring for up to 10 users; Support multi-stream real time transmission
Remote Monitoring	Webviewer browsing, Holis Pro, Holis Lite, ExacqVision, victor
API	ONVIF Profile (S, G & T), HAPI3, iAPI3
Interface
Network	1 RJ45 10M/100M self-adaptive ethernet port
Audio	Line IN × 1, Line OUT × 1
Video Output	CVBS video output ( BNC × 1 )
Onboard Storage	Built-in micro SD/SDHC/SDXC slot
Alarm	Alarm IN x 2, Alarm OUT x 2
Hardware Reset	Yes
Environmental
Operating Temperature	- 30 °C to 60 °C
Operating Humidity	10 % to 90 % relative humidity
General
Power Supply	AC24V / DC12V / PoE
Power Consumption	< 11W
Dimensions ( mm )	146.9 × 79 × 64
Material	Metals
Weight	≈ 0.65kg
Installation	Wall mounting, ceiling mounting
Certification	CE, FCC, UL, BIS
NDAA Compliant	Yes

Model Number

Description

Camera

ISV-X04N005SAF

H.265 4MP Box N/W Camera, 1/1.8" CMOS, C/S, DC12V/AC24V/PoE, SD,

Smart IVA, Facial Recognition/Identification
