EPIC ES-F501H Digital Finger Print Rim Door Lock
EPIC ES5011H Operation Model 4 WAY to OPEN
- FINGERPRINT
- CARD
- PIN NUMBER
- BLUETOOTH
Key Features
- Up to 200 RFID Cards can be registered
- Up to 100 Fingerprints can be registered
- Guest Pin Number registration
- 3 Level Administrator system
- Random Number Features that enhance Pin Number security
- Home Network Module and Remote Control OPTIONS
- Smart APP
- Front Body Dimension: 70(W)x 176(H) x 21 (D)MM
- Back Body Dimension: 75(W) x 187(H) x 55(D)MM
Main Features
- OUTER BODY (W X H X D mm) : 74mm x 176mm x 21mm
- INNER BODY (W X H X D mm) : 75mm x 187mm x 55mm
- MATERIAL : Zn, ABS
- APPLICABLE DOOR THICKNESS (mm) : 30 ~ 50mm
- OPERATION HUMIDITY : 30 ~ 50mm
- OPERATION TEMPERATURE : 0°C ~ 40°C
- FIER DETECTION TEMPERATURE : 60°C + 10°C
- POWER SUPPLY : DC 6V (LR6 1.5V AA, 4EA)
- EMERGENCY POWER : USB C-type 5V
- Battery Life (10 Times / 1 Day) : 10 months
Refund policy
Refund policy
we suggest to reach us out on +919825257770 or info@techfinder.in regarding the product you wish to shop before making an online purchase. Once you have made the transaction through techfinder, unless a legitimate reason, the order can neither be returned nor cancelled.In case of legitimate reason the return is acceptable only within 2 days(with video proof). Read more...
Shipping Info
Shipping Info
We always believe to provide smooth and easy shipping methods to our valued customers. We are committed to providing timely service and ensuring your satisfaction. Orders will be dispatched within 2 to 7 days, depending on the specific order and the product's availability. We appreciate your patience and understanding as we work to fulfill your request. The orders for the user are shipped through registered domestic courier companies and/or speed post only. Read more...
Remote door opening/closing
- Remotely control the door lock's
- opening and closing from the Main screen.
Sharing control permissions
- Through the Member feature, door lock access can be remotely shared with users.
Firmware update support
- Periodically update the firmware of the door lock being used through the Door Lock feature.
Smart push notifications
- Provide real-time access notifications to the administrator through the Wi-fi bridge feature.
Key registration
- Simplify the door lock authentication registration process through the Key feature.
Guest key creation and sharing
- Remotely share door lock access permissions for a specific period through the Guest Key feature.
Access history check
- Check and manage access records through the History feature.
Using apps in various languages
- Use the app in the preferred language by selecting it through the App Settings feature.
Adminstrator Functions
Super Adminstrator
- Super Admin Registration Mode
- Permission Setting
- Reset Registration information
- Bluetooth Pairing Standby mode
Smart Card Auto Recognition
- ON /OFF
- Set the MIFARE card recognition method.
Reset Registration
- Information
- (Without Super Admin)
Permission Setting
- (Without Super Admin)
General Admin
- Registration Mode
Deadbolt Auto Lock
- ON / OFF
- Set deadbolt locking method.
Sound Setting
- Set sound volume.
Door Open Alarm
- ON /OFF
- When the deadbolt is in the open state, an alert soundwill be played up to
- 3 times every 7 seconds.
Voice Mode / Buzzer Mode
- Setting
- select a voice guide or beep as needed.
Internal Forced Lock
- ON/OFF
- It is possible to forcibly lock the door from the inside to prevent the door lock from
- being unlocked.
External Forced Lock
- ON/ OFF
- It is possible to forcibly lock the door from the outside to prevent the door lock from
- being unlocked.
Alarm Notification
- ON/ OFF
- Set alarm sound volume.
Dual Authentication
- ON/OFF
- The door can only be unlocked after entering the user PIN Number and completing
- a second authentication.
FeliCa Auto-Detection
- ON/OFF
- Set the FeliCa card recognition method.
1 Minuite Lock Warning
- Function
- Total 5 consecutive failed will result in 1 minute suspension of authentication.
Etiquette Mode
- The door lock's sound can be muted when unlocking the door.
Dummy Number
- Features
- Using Dummy Numbers prevents the exposure of the PIN Number.
Automatic Re-Locking
- Features
- The door is not opened within 7 seconds after the door is unlocked by authentication, the Automatic Re-locking action will be executed.
Low Battery Warning
- Features
- When low battery is detected, the [Battery Replacement] LED lights up.
Deadbolt Operation Error
- Warning Function
- An error sound will occur if the deadbolt does not operate perfectly during the
- opening or closing.
Intrusion Alarm Function
- If the deadbolt sensor stops responding while the deadbolt sensor is on for more than 7 seconds, an intrusion alarm will occur.
High Temperature Alarm
- Function
- Alarm after deadbolt open operation during high temperature detection.
Emergency Battery
- Use a C-Type Cable
- when the battery is discharged.
