Technical Parametres

• Model: S80E45
• Color: black, silvery
• Material: Zinc alloy
• Battery: 4*AAA battery
• Supply voltage: 6V
• Quiescent current: <100uA
• Dynamic current: <200mA
• Low voltage alarm voltage: 4.5V
• Life time: >25,000 times opening
• Working temperature: -15°C ~ +65°C
• Different working modes: public and private

Along with This Lock

LOCK CASE

• Material : ABS
• Size : 80*80*27mm

STRICKER PLATE

• Material : ABS
• Size : 80*27*21.5mm

SCREW

• Screws for lock case installation(KA3*35)
• Screws for panel installation(KB3*25/30)
• Screws for plate installation(PA4*12)
• Screws for battery box installation(M2*12/M2*4)

CONNECTING WIRE & PROGRAMMING GUIDE :

DOWNLOAD

Extra Information

• SKU: S80E45
• Warranty: No Warranty
• Brand: EPIC
• Technology: Others
• Product Type: Electric Lock
• PDF: View PDF
