TVT TD 7451AS 5megapixel Ahd Ir Bullet Camera

TVT TD 7451AS 5megapixel Ahd Ir Bullet Camera

  • (0)
  • See All Review
  • Wishlist
2,500 3,500 29% Off
SKU : TVTBullet
Brand : TVT
Warranty : 2 Years

Description

  • 5MP real-time image, high resolution, true color
  • AHD / TVI / CVI standard and lossless video output
  • Up to 1400 TVL resolution
  • CMOS progressive scan, perfectly capture the moving object Support OSD menu
  • High speed, long distance and real time transmission
  • Auto color to B / W at low illumination
  • Support ICR switch, true day / night
  • 10 ~ 20m IR night view distance
  • IP66 ingress protection
  • Support COC

TVT TD-7451AS 5megapixel AHD Analog IR Bullet Camera

TVT 5mp Bullet Camera

Specification

 Model Specifications

TD-7451AS

Camera

Image Sensor

1 / 2.5 "CMOS

Resolution

5MP

Image Size

2560 x 1936

Video Output

AHD / TVI /CVI

Image System

PAL / NTSC

Electronic Shutter

Auto

IR Distance

10 ~20 m

Frame Rate

20fps

Min. Illumination

0 lux (IR ON)

Lens

3.6 mm

Lens Mount

M12

S / N Ratio

≥52dB ( AGC OFF )

Ingress Protection

IP 66

Functions

Function Control

OSD ( COC Control )

Day & Night

ICR

Digital WDR

Yes

Digital NR

Yes

Global Exposure

Yes

Central Exposure

No

AGC

Yes

Auto White Balance

Yes

BLC

Yes

LSC

No

Contrast

Yes

Sharpness

Yes

Smart IR

No

Image Setting

Yes

Defect Correction

Auto

Language

Chinese and English

Angle Adjustment

Pan: 0°~360°; Tilt:

0°~90°; Rotation: 0°~360°

Others

Power Supply

DC12V ( ± 15% )

Power Consumption

IR OFF : < 1W; IR ON : < 3.5W

Working Environment

- 30 °C ~ 50 °C, 10 % ~ 90 %(relative humidity)

Dimensions ( mm )

Ф 70 x 156

Weight ( net )

Approx. 0.3KG
